10 Pin DIP Switch

SKU: DT- ST002

10-pin DIP switch for configuration and selection of settings in electronic circuits.

The 10-pin DIP switch is a versatile electronic component used for configuring and selecting multiple options or settings in electronic circuits. It consists of a small rectangular package with ten inline pins that can be individually set to either an ON or OFF position. This switch is commonly used in digital devices, industrial control systems, and electronic prototypes where manual configuration or selection of settings is required.

Configuration Options: Provides multiple switch positions for setting various options.
Compact Size: Fits into standard DIP sockets or mounts directly on PCBs.
Individual Control: Each pin can be independently set to ON or OFF position.
Ease of Use: Allows manual setting of configurations without additional tools.
Durable Construction: Designed for reliable operation and long-term use.

Ensure correct alignment and soldering to maintain electrical contact.

Handle with care to avoid damage to the switch or PCB during installation.

Verify switch positions and functionality before integrating into circuits.

We offer a 7-day return policy for unused and undamaged items. If you are not completely satisfied with your purchase, you may return the item within 7 days of receipt for a full refund or exchange. The item must be in its original condition and packaging.
